SI7463ADP-T1-GE3

SI7463ADP-T1-GE3 Vishay Intertechnologies Trans MOSFET P-CH 40V 46A 8-Pin PowerPAK SO T/R

ManufacturerVishay Siliconix
SeriesTrenchFET®
PackagingTape & Reel (TR)
Part StatusActive
FET TypeP-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)40V
Current - Continuous Drain (Id) @ 25°C46A (Tc)
Drive Voltage (Max Rds On, Min Rds On)4.5V, 10V
Rds On (Max) @ Id, Vgs10mOhm @ 15A, 10V
Vgs(th) (Max) @ Id2.3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs144nC @ 10V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds4150pF @ 20V
FET Feature-
Power Dissipation (Max)5W (Ta), 39W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackagePowerPAK® SO-8
Package / CasePowerPAK® SO-8
