SFH615A-3X009T

SFH615A-3X009T Vishay Intertechnologies Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin PDIP SMD T/R

ManufacturerVishay Semiconductor
Series-
PackagingCut Tape (CT)
Part StatusActive
Number of Channels1
Voltage - Isolation5300Vrms
Current Transfer Ratio (Min)100% @ 10mA
Current Transfer Ratio (Max)200% @ 10mA
Turn On / Turn Off Time (Typ)3µs, 2.3µs
Rise / Fall Time (Typ)2µs, 2µs
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)70V
Current - Output / Channel50mA
Voltage - Forward (Vf) (Typ)1.35V
Current - DC Forward (If) (Max)60mA
Vce Saturation (Max)400mV
Operating Temperature-55°C ~ 100°C
Mounting TypeSurface Mount
Package / Case4-SMD, Gull Wing
Supplier Device Package4-SMD
